Specifications
| Wattage | 0.5W Max. (transmitting power) < 1.5W (stand-by power) |
| DC Input Voltage | N/A |
| Rated Voltage | 120V AC / 277V AC / 347V AC, 50/60Hz |
| Working Mode Output | On/OFF function, 1-10V step dimming |
| Dim Interface | < 50mA (non-constant source) 10% (1.4-1.6V) / 20% (1.9-2.1V) / 30% (2.9-3.1V) / 50% (4.9-5.1V) |
| Operating Frequency | 5.8 GHz ± 75MHz, ISM Band |
| Lifetime | 50000 hours |
| Grade of Protection | IP 65 |
| Protection Class | Class II |
| Environment Requirement | Compliant to RoHS |
| Wiring | Input STW, 3*18AWG exposed line length: 810-830 mm 1-10V DC: STJW, 2*18AWG exposed line length: 810-830 mm |
| Detection Angle | 150° (wall mounting) 360° (ceiling mounting) |
| Hold Time | DIP switch: 5s / 30s / 1min / 3min / 20min / 30min Remote control: 5s / 30s / 1min / 3min / 5min / 10min / 20min / 30min |
| Stand-by Dim Level | DIP switch & Remote control: 10% / 20% / 30% / 50% |
| Stand-by Period | DIP switch: 0s / 1min / 3min / 10min / 30min and so forth Remote control: 0s / 10s / 1min / 3min / 5min / 10min / 30min and so forth |
| Detection Area | DIP switch: 100% / 50% Remote control: 25% / 50% / 75% / 100% |
| Daylight Sensor | DIP switch & Remote control: 5lux / 15lux / 30lux / 50lux / 100lux / 150lux / Disable (ambient light diffusion) |
| Detection Radius | 5-8m (mounting height 8m, maximum mounting height 15m) |
| Operating Temperature | -35°C ~ +55°C |
