Work for 110-277V AC input, 120V and 277V dimmers, allows for flicker free dimming down to 1%
Flicker-free and compatible with Forward phase, Reverse phase, TRIAC, MLV, ELV Dimmers
PWM (Pulse-Width Modulation) output, does not change the colour index
Match with TRIAC, electronic low voltage, magnetic low voltage dimmers
Full protection aluminum housing for dry / damp locations
Suitable for LED lighting and moving sign applications
High efficiency: up to 86% and Min.Load 10% only
Cooling by free air convection

International Shipment

Your orders are shipped seamlessly between countries

30 Days Warranty

You have the right to return your orders within 30 days.

Secure Payment

Your payments are secure with our private security network.

Input Voltage	110-277V AC
Output Voltage	12V DC
Maximum Wattage	300W
Amps	25A
Dimmable	Yes
Frequency Range	47-63Hz
Power Factor	0.99 at 120V AC 0.97 at 277V AC
Efficiency (Typ.)	86%
AC Current (Max.)	3.4A at 110V AC
Short Circuit	Shut down o/p voltage; Repower on to recover after fault condition is removed
Over Loading	120%
Operating Temperature	-40ºC ~ +60ºC
Operating Humidity	20-90%RH, non-condensing
Safety Standards	UL 8750
Withstand Voltage	I/P-O/P: 1880V AC
Isolation Resistance	I/P-O/P: 100MΩ / 500V DC / +25ºC / 70% RH
Warranty	5 years
Case Quantities	10

Reviews

There are no reviews yet.

Be the first to review “OT-12300-TDWJMaximu – m 300W class 2 LED Driver available in 12V DC output”
